PSA Nitrogen Generator GAN Pressure Swing Adsorption 99.5% N2 ASP

Hangzhou Hangyang Cryogenic Liquefaction Equipment Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

PSA Nitrogen Generator GAN Pressure Swing Adsorption 99.5% N2 ASP

Brand Name : HANGYANG
Model Number : VPSA-300Nm3/h (N2) PSA Nitrogen Generator
Certification : CE/ASEM/GB
Place of Origin : China
MOQ : 1 SET
Price : according to actual requirement
Supply Ability : according to actual requirement
Delivery Time : according to actual requirement
Packaging Details : wooden case, nude packing, container
Product Name : PSA Nitrogen Generator
Usage : Produce nitrogen
Output : ≥150 Nm3/h (GAN)
Type : VPSA
Dew point : <42℃
Temperature : 27 ℃
Delivery Term : FOB Shanghai
Contact Now

VPSA-300Nm3/h (N2) PSA Nitrogen Generator


Output, purity and pressure


Product

Pressure ex. battery limit of plant

MPa (G)

Temperature

°C

Purity Index

Output

Nm3/h

Nitrogen

0.80

~27

≥99.5%N2

≥300

Instrument Air

0.65

~27

Oil-free, water-free, dust-free

Dew point<-42℃

2.0


Process Description:


Regarding the adsorbed gas (adsorbate) for any adsorbent, under the adsorption equilibrium, the lower temperature, higher pressure, the bigger adsorption capacity. On the contrary, higher temperature, lower pressure, the smaller adsorption capacity. So the adsorption and separation methods of gases usually employ two circulating processes of temperature swing adsorption and pressure swing adsorption.

If the pressure is invariant, under normal temperature or low temperature condition, it utilizes high temperature desorption method, which is called temperature swing adsorption. Due the large specific heat capacity of adsorbent, and small heat conductivity, it needs long time for warming and cooling, and the operation is troublesome. So the temperature adsorption mainly used to purify the gas with less adsorbate.

If the temperature is invariant, under the condition of pressuring, it utilizes decompression or normal pressure desorption method, which is called pressure swing adsorption. It is obvious that pressure swing adsorption conducts adsorption and desorption through changing pressure.



Applications:


We supplied many countries (USA, Germany, Mexico, Indonesia, North Korea, Kazakhstan, Iran, Saudi Arabia, Egypt, Brazil, Hungary, Malaysia, Czech, Switzerland, Spain, Myanmar, Vietnam, Thailand, Russia, Mongolia, Syria, India, etc.)


Competitive advantage:


1. The Seller will provide the related technical documents, like pressure vessel certification, operation manual.

2. The Seller will provide the technical guidance for plant installation, and be responsible for the commissioning of the plant and training for operator.

3. When finishing the manufacturing of complete plant, it can be delivered only after all technical indexes are qualified after being tested.

4. All valves will be tested, the safety valves of vessels and electrical part will be detected.

5. The company established common spare parts storage to adequately assure the various demands of user.
